The UPD166101GR parts manufactured by NEC are available for purchase at autoecuchips.com . Here you can find various types and values of electronic parts from the world's leading manufacturers. The UPD166101GR components of autoecuchips.com are carefully chosen, undergo stringent quality control, and are successfully meet all required standards.
The production status marked on autoecuchips.com is for reference only. If you didn't find what you were looking for, you can get more valuable information by emails, such as the UPD166101GR Inventory quantity, preferential price, datasheet, and manufacturer. We are always happy to hear from you, so feel free to contact us.
Below are detailed information about the UPD166101GR chip:
- Features : N-channel low-side smart power device with low on-resistance, high withstand voltage, and fast switching speed to provide efficient power conversion and good thermal performance.
Applicable Models and Brands
UPD166101GR chips are widely used in the electronic control systems of many automobile brands and models, the following are some common models and brands:
- Toyota: such as the ECU and body electronic system of Toyota Corolla, Camry and other models.
- Honda: ECU and motor control system of Honda Accord, Civic and other models.
- Nissan: ECUs and body electronic systems for models such as Nissan Hennessey and Sky.
- Hyundai Kia: ECU and instrument panel of Hyundai Elantra, Sonata, Kia K3, K5 and other models.
Parameter Details
- Maximum drain-source voltage (Vds): usually 330V.
- Maximum gate source voltage (Vgs): typically ±20V.
- Continuous drain current (Id): 15A max.
- On-resistance (Rds(on)): Approx. 0.09Ω at Vgs = 10V.
- Power loss (Pd): 3.1W max.
- Operating temperature range (Tj) : Typically - 40°C to + 150°C.
- Package Size: SOP-8 package size is approximately 7.5mm x 4.4mm x 1.8mm.
Precautions
- Compatibility : Before purchasing, be sure to check if the UPD166101GR chip is compatible with your car model and ECU system, we recommend referring to your car's official service manual or consulting with a professional service technician.
- Installation and Soldering:
- Be careful to control the temperature and time when soldering to avoid damage to the chip.
- Connect the circuit according to the correct pin definition to prevent the chip from working or being damaged due to wrong wiring.
- Add necessary protection circuits in the circuit design, such as over-voltage protection, over-current protection, etc., to ensure the stable operation of the chip in the automotive electronic system.
- Use suitable decoupling capacitors to minimize the impact of power ripple on the chip.
- Technical Support : If you encounter technical problems while using the UPD166101GR chip, you can try to contact the technical support department of the chip manufacturer, or seek help from other engineers and enthusiasts in technical forums and communities.
