The following are detailed specifications for the ADM2486BRWZ chip:
**Chip Overview**
- **Model:** ADM2486BRWZ
- **Package Type:** 16-Lead SOIC_W (Wide-body SOIC-16)
- **Manufacturer:** Analog Devices
- **Applications:** Primarily used in fields such as industrial automation, communication networks, and automotive electronics. It is suitable for RS-485/RS-422 communication systems requiring electrical isolation—such as PROFIBUS networks, multipoint data transmission systems, and isolated interfaces.
**Technical Specifications**
- **Communication Protocol:** Half-duplex isolated RS-485 transceiver
- **Data Rate:** 20 Mbps
- **Operating Voltage Range:**
- **Logic Side (VDD1):** 3.3 V or 5 V
- **Bus Side (VDD2):** 5 V (requires isolated power supply)
- **Isolation Voltage:** 2500 Vrms (UL 1577 certified)
- **Common-Mode Transient Immunity:** >25 kV/μs
- **Node Count:** Up to 50 nodes on the bus
- **Operating Temperature Range:** -40°C to +85°C (Industrial Grade)
- **Key Features:**
- Compliant with ANSI EIA/TIA-485-A and ISO 8482:1987(E) standards
- PROFIBUS compatible
- Utilizes iCoupler® magnetic isolation technology; integrates a 3-channel isolator, a tri-state differential line driver, and a differential input receiver
- Isolated DE status output
- Receiver open-circuit fail-safe design
- Thermal shutdown protection
- Active-high Driver Enable (DE) and Receiver Disable (RE) functions
**Important Notes**
- **Compatibility:** Before purchasing, please verify that this chip is compatible with your specific application.
- **Installation Guidelines:**
- Ensure that the supply voltage complies with the chip's specifications.
- Use appropriate decoupling capacitors to minimize noise.
- Operate the device within the specified temperature range.
- **Technical Support:** If further technical assistance is required, it is recommended to contact the supplier or the manufacturer. Summary
The ADM2486BRWZ is a high-performance, half-duplex iCoupler® isolated RS-485 transceiver manufactured by Analog Devices. It is suitable for a wide range of industrial and automotive electronics applications, excelling particularly in multi-point bus communication systems where electrical isolation is required. Its high data rates, high common-mode transient immunity, and comprehensive protection features ensure exceptional practicality and reliability in the field of isolated communication.
