10PCS Original BKA30-R6 Automotive Instrument Stepper Motor Universal VID29-06 Instrument Cluster Repair Motor
The BKA30-R6 parts manufactured by autoecuchips.com are available for purchase at Autoecuchips.com. Here you can find various types and values of electronic parts from the world's leading manufacturers. The BKA30-R6 components of Autoecuchips.com are carefully chosen, undergo stringent quality control, and are successfully meet all required standards.
The production status marked on Autoecuchips.com is for reference only. If you didn't find what you were looking for, you can get more valuable information by emails, such as the BKA30-R6 Inventory quantity, preferential price, datasheet, and manufacturer. We are always happy to hear from you, so feel free to contact us.
BKA30-R6 is an automotive grade stepper motor produced by BKA Motor, widely used in automotive dashboard pointer drive. Below are the detailed information about this motor:
- Features:
- High accuracy: 1/3° step-by-step accuracy, 1/12° micro-step accuracy.
- Low power consumption: average operating current 15-20mA
- Small size: Φ30 x 7.25mm
- Wide operating temperature range: -40°C to +105°C
- Low noise: operating noise as low as 38-40dB(A).
- Long life: Wear-resistant and noise-reducing gear material.
- High reliability: in line with automotive industry standards
Technical Parameters
- Dimensions:
- Motor diameter: Φ30mm
- Motor height: 7.25mm
- Output shaft outer diameter: Φ1.0mm
- Output shaft height: 10.95mm
- Tab O.D. x Height: Φ4.2 x 5.8mm
- Electrical parameters:
- Working voltage: 5V
- Coil resistance: 260-300Ω
- Operating current: 15-20mA (at 200Hz frequency)
- Maximum driving frequency: 600Hz
- Dynamic torque: 1.0-1.3mNm (at 200Hz frequency)
- Static torque: 3.5-4.0mNm (at 5V voltage)
- Mechanical parameters:
- Axial thrust: 100-120N
- Axial pull force: 80-100N
- Radial thrust and pull: 12-15N
- Maximum angular acceleration: 1,000 rad/s²
- Holding torque: 90-120 mNm
- Maximum freewheeling angle: 320°
- Operating temperature range: -40°C to +105°C
- Sound level: 38-40dB(A)
Application Scenarios
- Automotive instrument panel pointer drive: for speedometer, tachometer, water temperature gauge, oil gauge, etc.
- Automotive electronic systems: for a variety of automotive electronic modules that require high precision and low power consumption.
Cautions
- COMPATIBILITY: Before purchasing, please make sure the motor is compatible with your car's dashboard.
- Technical Support: If further technical support is required, it is recommended to contact the supplier or manufacturer.
- STORAGE CONDITIONS: It is recommended to store in a dry storage cabinet to avoid moisture.
Summarization.
The BKA30-R6 is a high-performance automotive-grade stepper motor for a wide range of automotive dashboard pointer drive applications. Its high precision, low power consumption and low noise characteristics make it an excellent performer in automotive electronic systems.
