The
BTN8962TA is a high-performance, high-current half-bridge driver, available from stock at
autoecuchips.com, which is suitable for automotive motor drive applications. Its low EMI design, integrated protection features and compact package make it an ideal automotive electronic control solution. If you need further technical support or purchasing advice, you can contact us on whatsapp
+8618718921345 or check the datasheet.
Technical Specifications
- Pass Through Resistance:
- Maximum: 30.3 mΩ (150°C)
- Typical: 14.2 mΩ (25°C) - High side: 13.4 mΩ max.
- High Side: 13.4 mΩ (150°C) maximum, 6.7 mΩ (25°C) typical
- Low Side: 16.9 mΩ maximum (150°C), 7.5 mΩ typical (25°C)
- Switching Speed: Enhanced switching speed for reduced switching losses.
- PWM Frequency: Supports high-frequency PWM combined with active continuity.
- Quiescent Current: 7 µA typical (25°C).
- Current Limit:
- Minimum: 30 A
- Supports switching mode current limiting to reduce power loss in overcurrent condition.
- Diagnostic Functions:
- Current sense function for status flag diagnostics.
- Protection Functions:
- Over-temperature shutdown (with latching behavior).
- Undervoltage shutdown.
- Driver circuit:
- Logic level input.
- Adjustable slew rate for EMI optimization.
- Operating Voltage: Up to 40V.
- Environmental Standards: RoHS compliant.
- Certifications: AEC certified. Key Features 1. High Current Handling:
- High Current Handling Capability: High-side and low-side MOSFETs provide high current handling capability. 2.
2. Low EMI design:
- Low EMI design: P-channel high-side switching eliminates the need for charge pumps and minimizes EMI. 3.
3. Integrated Protection:
- Over-temperature, under-voltage, over-current and short-circuit protection. 4.
4. Low quiescent current:
- Suitable for low power applications. 5.
5. High reliability:
- Complies with AEC-Q100 standard for automotive grade applications. 6.
6. Compact package:
- TO-263-7 package saves board space.
Application Scenarios
- Automotive electronics:
- Electronic Parking Brake (EPB).
- Active Suspension Control.
- Fuel Pump Control.
- Fuel Pump Control. Drivetrain Control (T-Case).
- Industrial applications:
- High current motor drives.
