The following are detailed information about the BTS5590G chip:
Technical Specifications
- Operating Voltage Range: 9V to 16V (Typical 13.5V)
- Continuous Output Current: 3.5A per Channel (Maximum 5.5A)
- On-Resistance:
- Channels 0, 1, 2: 200mΩ (Typical)
- Channels 3, 4: 80mΩ (Typical)
- Operating Junction Temperature Range: -40°C to +150°C (Automotive Grade)
- Key Features:
- Five-channel high-side power switch
- Integrated short-circuit protection
- Overtemperature shutdown protection
- Open load detection
- Supports PWM modulation input
- AEC-Q100 compliant
- Integrated watchdog function
- SPI interface for configuration and diagnostics
- Supports daisy chain configuration
- Provides current sense signal
- ESD protection (HBM ±4kV)
Notes
- Compatibility: Before purchasing, please confirm whether this chip is compatible with your application.
- Installation Instructions:
- Ensure the power supply voltage meets the chip specifications.
- Use appropriate decoupling capacitors to reduce noise.
- Operate the device within the specified temperature range.
- Technical Support: If further technical support is required, it is recommended to contact the supplier or manufacturer.
Summary
The BTS5590G is a high-performance automotive-grade smart high-side switch manufactured by Infineon. It is suitable for a variety of automotive electronic applications, especially in automotive BCMs and headlight control systems. Its low on-resistance, comprehensive protection features, and diagnostic feedback make it highly practical and reliable in automotive electronic systems.
