New original G8ND-2U Relay G8ND-2UK-12VDC DIP8 G8ND BMW Handbrake Relay X5 X6 E70E71 Electronic Handbrake Motor Repair
Application:
FOR Renault Scenics 2004 - 2015
FOR BMW X5 07-13 year E70 08-12 year
FOR BMW X6 08-14 year E71 E72 09-13 year
Replacement Relay for Handbrake Failure with Electronic Handbrake
34436850289
Category: Electronic parking brake actuator parts.
Typical applications include:
(1) Power windows/power door lock;
(2) Smart junction box and module applications;
(3) Seat adjustment;
(4) Sunroof.
Output Type: DC
On-State Resistance: 6 mOhm
Load Current: 25mA
Package / Case: 8-DIP
Load Voltage Rating: 0 ~ 60 V
Operating Voltage: 48-660V
Transient Overvoltage: 600Vpk
Control Voltage Range: 4-10 VDC
Package including:
1PCS Omron G8ND-2UK 12VDC relay
Below are detailed information about the G8ND-2UK-12VDC chip:
Technical parameters
- Operating voltage: 12V DC
- Coil resistance: 225Ω
- Coil current: 53.3mA
- Contact form: 1 Form C (SPDT-NO, NC)
- Maximum switching current: 30A
- Maximum load current: 25A (at 12VDC for 2 minutes)
- Operating time: 10ms max (at 20°C)
- Release time: 5ms max. at 20°C
- Insulation resistance: 100MΩ minimum (at 500VDC)
- Operating temperature range: -40°C to +105°C
- Storage temperature range: -40°C to +125°C
- Number of pins: 8
Functional Features
- High current carrying capacity: Each contact can carry up to 30A of current, ensuring reliability in high load applications.
- Fast switching: Low operation and release times ensure fast response to control signals.
- Long life: Mechanical durability of over 1,000,000 operations for frequent use applications. Multiple protection functions: Includes thermal protection and a wide range of protection functions.
- Multiple Protection Functions: Includes thermal and short-circuit protection to ensure the safety of the chip in abnormal conditions.
- Compact package: DIP-8 package with small size for space-constrained board designs.
- Low power consumption: Low typical power consumption for battery-powered portable devices.
Applicable Models and Brands
- BMW: Used in BMW handbrake system to solve the handbrake problem.
- Renault: for Renault Scenics models, 2004 - 2015.
Caution.
- COMPATIBILITY: Before purchasing, please make sure the relay is compatible with your car's electronic system.
- Installation Instructions:
- Make sure the relay is mounted in the correct orientation and the pins are aligned with the circuit board pads.
- During soldering, pay attention to temperature control to avoid overheating and damaging the relay.
- Take appropriate static protection measures to avoid static electricity damage to the relay.
- Technical Support: If further technical support is required, it is recommended to contact the supplier or manufacturer.
Summary
G8ND-2UK-12VDC is a high-performance automotive relay manufactured by Omron for use in a wide range of automotive electronics applications. Its high current carrying capacity, fast switching speed, and long life make it an excellent performer in automotive electronic systems. During use, please ensure its compatibility with your car's electronic system, and install and operate it according to the specifications.
