10pcs L4925N IC TO220-5 Repair Mitsubishi Pajero instrument Does Not Work Power Supply Triode Control Module ST Original Chip
The L4925N parts manufactured by ST are available for purchase at Autoecuchips.com. Here you can find various types and values of electronic parts from the world's leading manufacturers. The L4925N components of Autoecuchips.com are carefully chosen, undergo stringent quality control, and are successfully meet all required standards.
The production status marked on Autoecuchips.com is for reference only. If you didn't find what you were looking for, you can get more valuable information by emails, such as the L4925N Inventory quantity, preferential price, datasheet, and manufacturer. We are always happy to hear from you, so feel free to contact us.
Below you will find detailed information about the L4925N including technical specifications, application scenarios, datasheet downloads and purchasing information:
- Features:
- Operating voltage range: 6V to 28V
- Transient voltage capability: up to 40V
- Very low quiescent current
- Highly accurate output voltage (5V)
- Maximum output current: 500mA
- Very low dropout voltage: less than 0.6V
- Built-in reset circuit to monitor output voltage
- Reset pulse delay programmable via external capacitor
- Thermal shutdown and short-circuit protection are provided.
Technical Parameters
- Operating voltage range: 6V to 28V
- Transient voltage withstand capability: up to 40V (duration less than 1s)
- Output voltage: 5V (accuracy ±1.5%)
- Maximum output current: 500mA
- Static current: 10mA typical (operating), very low quiescent current (standby)
- Dropout voltage: less than 0.6V (at 100mA output current)
- Reset threshold voltage: 4.5V
- Reset pulse delay: programmable via external capacitor
- Operating temperature range: -40°C to +125°C (automotive grade)
- Storage temperature range: -55°C to +150°C.
Pin Functions
- Pin 1: Input voltage (V_in)
- Pin 2: Output voltage (V_out)
- Pin 3: Reset signal (Reset)
- Pin 4: Ground (GND)
- Pin 5: External capacitor connection for programmed reset delay (C_delay)
Cautions
- COMPATIBILITY: Before purchasing, please make sure the chip is compatible with your application.
- Installation Instructions:
- Ensure that the supply voltage meets the chip specifications.
- Use appropriate decoupling capacitors to minimize noise.
- Operate the device within the specified temperature range.
- Technical Support: If further technical support is required, it is recommended to contact the supplier or manufacturer.
Summary
The L4925N is a high-performance, low dropout voltage regulator from STMicroelectronics for a wide range of automotive electronics applications. Its high accuracy output voltage, low dropout voltage, and multiple protection features make it an excellent performer in automotive electronic systems.
Welcome to our shop!
Dear friends, if you are very interested and want to order a large number, you can contact us through Whatsapp, Wechat, email or Skype, and we will reply to you within 24 hours.
Product Description:
1.The picture only supplies the reference It may not be the exact one as in our stock because of difr NO.
2.We will ship the items within 3 working days after the payment is reached.
3.When the parts arrive at your local customs, if the parts are charged with customs duties, we are not responsible for any customs duties or import taxes.
REFUNDS & RETURN:
We offer a warranty on all items that we sold. Item will be tested before ship, it will be in good condition, if there are some problems with the item, feel free to contact us.
You must contact us before returning any product . Return must be in new condition (Buyer should return all original and undamaged items under re-saleable condition).
Return the goods and the buyer is responsible for all expenses!!
If you are satisfied with our products, please give positive feedback. Thank you for your help. If you are not satisfied, please let us know. Your constructive suggestions will become the driving force for our modification and improvement. Thanks for your understanding.
