The LM139DR parts manufactured by Texas Instruments are available for purchase at Autoecuchips.com. Here you can find various types and values of electronic parts from the world's leading manufacturers. The LM139DR components of Autoecuchips.com are carefully chosen, undergo stringent quality control, and are successfully meet all required standards.
The production status marked on Autoecuchips.com is for reference only. If you didn't find what you were looking for, you can get more valuable information by emails, such as the LM139DR Inventory quantity, preferential price, datasheet, and manufacturer. We are always happy to hear from you, so feel free to contact us.
- **Features**:
- Quad differential input voltage comparators
- Wide supply voltage range: 2 V to 36 V (single supply), ±1 V to ±18 V (dual supply)
- Low supply current: 0.8 mA (typical), independent of supply voltage
- Low input bias current: 25 nA (typical)
- Low input offset current: 3 nA (typical, LM139)
- Low input offset voltage: 2 mV (typical), 5 mV max @ 25°C
- Common-mode input voltage range includes ground
- Differential input voltage range equal to maximum rated supply voltage: ±36 V
- Low output saturation voltage
- Output compatible with TTL, MOS, and CMOS
- Open-collector output; supports Wired-AND connections
- Propagation delay: 300 ns (typical), 1.3 µs (maximum)
- Automotive-grade operating temperature range: -55°C to +125°C
Technical Specifications
- **Number of channels**: 4 (four independent comparators)
- **Output type**: Open-collector / Open-drain
- **Supply voltage range (single supply)**: 2 V to 36 V
- **Supply voltage range (dual supply)**: ±1 V to ±18 V
- **Input offset voltage (max)**: 5 mV @ 30 V
- **Input bias current (max)**: 0.1 µA @ 5 V (100 nA)
- **Input bias current (typical)**: 25 nA
- **Input offset current (typical)**: 3 nA
- **Output current (typical)**: 20 mA
- **Quiescent current (max)**: 2 mA
- **Propagation delay time**: 300 ns (typical), 1.3 µs (maximum)
- - **Common-mode input voltage range**: 0 V to VCC - 1.5 V (includes ground)
- **Differential input voltage range**: ±36 V
- **Operating temperature range**: -55°C to +125°C
- **Package type**: SOIC-14 (D package, 0.154" / 3.90 mm wide)
- **Mounting type**: Surface Mount (SMT)
- **Packaging**: Tape & Reel (2,500 units/reel)
- **RoHS status**: Lead-free / RoHS compliant (G4 suffix indicates the eco-friendly version)
- **Product lifecycle**: Active (in mass production)
Notes
- **Compatibility**: Please verify compatibility with your application before purchase.
- Package match: SOIC-14 (14-pin, 3.90 mm wide); verify PCB pad design
- Supply voltage: Single supply 2V–36V or dual supply ±1V–±18V
- Output type: Open-collector; requires an external pull-up resistor to the positive supply
- Temperature range: -55°C to +125°C (automotive grade); ensure the application's ambient temperature is within this range
- Suffix distinction: DR = Tape & Reel, D = Tube, G4 = Eco-friendly version
- **Installation instructions**:
- ESD protection: The chip is sensitive to electrostatic discharge; wear an anti-static wrist strap before handling
- Soldering temperature: Reflow peak temperature ≤260°C; compliant with lead-free soldering standards
- Pull-up resistor: Open-collector output requires an external pull-up resistor (typically 1kΩ–10kΩ) connected to VCC
- Decoupling capacitor: A 0.1 µF ceramic decoupling capacitor connected in parallel from the VCC pin to ground is recommended
- Input protection: Differential input voltage can reach ±36V, but avoid prolonged operation exceeding the supply voltage
- Operate the device within the specified temperature range
- **Troubleshooting**:
- Output stuck low: Check if the pull-up resistor is connected, verify the VCC supply is normal, and ensure the input signal is within the common-mode range.
- No output response: Check if the input signal exceeds the differential voltage range and verify if the chip is damaged.
- Slow response speed: Check if the load capacitance is excessive and ensure the pull-up resistor value is appropriate.
- Abnormal power consumption: Check if the quiescent current exceeds 2 mA and verify if there is an output short circuit.
- Output conflict with multiple chips in parallel: Ensure that the outputs of the chips do not conduct simultaneously, which would cause a short circuit.
- **Alternative Model References**:
- LM139D (SOIC-14 tube packaging version)
- LM139ADR (High-precision version, input offset voltage 2 mV max)
- LM139J (CDIP-14 ceramic dual in-line package)
- LM239DR (Industrial grade, -25°C to +85°C)
- LM339DR (Commercial grade, 0°C to +70°C)
- LM2901DR (Automotive grade extended temperature, -40°C to +125°C)
- Select alternative models based on specific temperature grade and precision requirements.
- **Technical Support**: For further technical support, it is recommended to contact Texas Instruments or a professional electronic component distributor.
Summary
The LM139DR is a quad differential-input voltage comparator manufactured by Texas Instruments, housed in an SOIC-14 package. Its wide supply voltage range (2V–36V single supply / ±1V–±18V dual supply), low power consumption (0.8 mA typical quiescent current), low input bias current (25 nA), low input offset voltage (2 mV typical, 5 mV maximum), and automotive-grade operating temperature range (-55°C to +125°C) make it an ideal choice for high-reliability applications such as automotive electronics, industrial control, instrumentation, and power management. The chip's open-collector output supports wired-AND connections and parallel operation with multiple devices, and it is compatible with TTL, MOS, and CMOS logic. Logic levels. During maintenance, attention must be paid to package compatibility, pull-up resistor configuration, supply voltage range, and temperature grade selection to ensure stable system operation.
