5pcs LM5030MMX LM5030MM LM5030 Marking S73B Switching Control/voltage Regulator Chip Repair IC
The LM5030MMX parts manufactured by autoecuchips.com are available for purchase at Autoecuchips.com. Here you can find various types and values of electronic parts from the world's leading manufacturers. The LM5030MMX components of Autoecuchips.com are carefully chosen, undergo stringent quality control, and are successfully meet all required standards.
The production status marked on Autoecuchips.com is for reference only. If you didn't find what you were looking for, you can get more valuable information by emails, such as the LM5030MMX Inventory quantity, preferential price, datasheet, and manufacturer. We are always happy to hear from you, so feel free to contact us.
LM5030MMX Details
The LM5030MMX is a high voltage PWM controller manufactured by Texas Instruments for current mode control of push-pull, half-bridge, and full-bridge topologies. Detailed information about the chip is provided below:
- Features:
- Built-in high voltage startup regulator
- Single resistor setting oscillator
- Synchronizable
- Error amplifier
- Precision reference
- Adjustable soft start
- Dual mode overcurrent protection
- Ramp Compensation
- Direct Optocoupler Interface
- 1.5-A peak gate driver
- Thermal shutdown
Technical Data
- Operating voltage range: 14V to 100V
- Package Type: VSSOP-10
- Number of pins: 10
- Operating temperature range: -40°C to +125°C
- Storage conditions: Dry storage cabinets, moisture-proof packaging
Application Scenarios
- Telecom power converters: for efficient power conversion.
- Industrial power converters: for power management in industrial equipment.
- Automotive systems: For +42V automotive systems such as automotive electronic control units (ECUs).
- DC-DC Converters: For DC-DC converter applications with input voltages up to 100VDC and output power in the range of 15W to 150W.
Precautions
- Compatibility: Before purchasing, please make sure the chip is compatible with your application.
- Technical Support: If further technical support is required, it is recommended to contact the supplier or manufacturer.
- STORAGE CONDITIONS: It is recommended to store in a dry storage cabinet to avoid humidity.
SUMMARY
The LM5030MMX is a high-performance, high-voltage PWM controller for a wide range of power conversion applications. Its built-in high-voltage startup regulator, single-resistance setup oscillator, and multiple protection features make it an excellent performer in telecom, industrial, and automotive systems.
