The MUSES02 parts manufactured by New Japan Radio Co., Ltd. are available for purchase at Autoecuchips.com. Here you can find various types and values of electronic parts from the world's leading manufacturers. The MUSES02 components of Autoecuchips.com are carefully chosen, undergo stringent quality control, and are successfully meet all required standards.
The production status marked on Autoecuchips.com is for reference only. If you didn't find what you were looking for, you can get more valuable information by emails, such as the MUSES02 Inventory quantity, preferential price, datasheet, and manufacturer. We are always happy to hear from you, so feel free to contact us.
The following are detailed specifications for the MUSES02 chip:
- Features:
- High-quality operational amplifier with bipolar input
- Low noise (4.5 nV/√Hz)
- High gain bandwidth (110dB)
- Low distortion
- Suitable for high-fidelity audio applications
Technical Parameters
- Operating voltage range: ±3.5V to ±16V
- Input offset voltage: 0.3mV (typical), 3mV (maximum)
- Input bias current: 100nA (typical), 500nA (maximum, Ta=25°C)
- Voltage gain: 110dB (typical)
- Slew rate: 5V/μs (typical)
- Output current: 50mA per channel
- Package type: DIP-8
- Number of pins: 8
- Operating temperature range: -40°C to +85°C
- Storage temperature range: -50°C to +150°C
Pin Configuration
Pin Number | Function
1 | A Output
2 | A Negative Input
3 | A Positive Input
4 | V-
5 | B Positive Input
6 | B Negative Input
7 | B Output
8 | V+
Applications
The MUSES02 is suitable for a variety of high-fidelity audio applications, including but not limited to:
- Audio preamplifiers: Providing high-fidelity audio signal amplification
- Active filters: Used for audio signal processing
- Line amplifiers: Used for audio signal transmission and amplification
- DAC output buffering: Used for output buffering of digital-to-analog converters
- High-impedance sensor amplifiers: Used for amplifying high-impedance signals
Precautions
- Compatibility: Before purchasing, please confirm that the chip is compatible with your application and circuit design.
- Installation instructions:
- Ensure that the soldering temperature meets the specifications.
- Avoid exceeding the rated voltage and current during use.
- Operate and store the device within the specified temperature range.
- Technical support: For further technical support, it is recommended to contact the supplier or manufacturer. Summary
The MUSES02 is a high-performance bipolar input, high-fidelity operational amplifier manufactured by New Japan Radio, suitable for a variety of high-fidelity audio applications. Its low noise, wide gain bandwidth, and low distortion rate make it an excellent choice for audio equipment.
Welcome to our shop!
Dear friends, if you are very interested and want to order a large number, you can contact us through Whatsapp, Wechat, email or Skype, and we will reply to you within 24 hours.
Product Description:
1.The picture only supplies the reference It may not be the exact one as in our stock because of difr NO.
2.We will ship the items within 3 working days after the payment is reached.
3.When the parts arrive at your local customs, if the parts are charged with customs duties, we are not responsible for any customs duties or import taxes.
REFUNDS & RETURN:
We offer a warranty on all items that we sold. Item will be tested before ship, it will be in good condition, if there are some problems with the item, feel free to contact us.
You must contact us before returning any product . Return must be in new condition (Buyer should return all original and undamaged items under re-saleable condition).
Return the goods and the buyer is responsible for all expenses!!
If you are satisfied with our products, please give positive feedback. Thank you for your help. If you are not satisfied, please let us know. Your constructive suggestions will become the driving force for our modification and improvement. Thanks for your understanding.
