PM20T-036 Instrument Stepper Motor Repair Audi A6L A4L Wuling Beetle Peugeot Citroen Fiat

The PM20T-036 is a high performance automotive instrumentation stepper motor for a wide range of automotive instrument cluster systems. are available for purchase at Autoecuchips.com.It features low noise, high torque and high accuracy, making it an ideal automotive instrumentation control solution. If you need further technical support or purchase advice, you can contact whatsapp +8618718921345 or check the datasheet.

Technical Specifications:

• Operating voltage: 12V (DC).

• Maximum external torque: 28.4 mNm.

• Maximum rotation angle: 340°.

• Motor type: permanent magnet stepper motor.

• Excitation mode: Variable reluctance (VR).

• Operation mode: three-phase single wire.

• Motor Type: Magnetoelectric.

•Peculiarity:

• Very low noise (<22 dBA). • High torque. • High precision. • Fast start-up speed and high rotational speed. • Long service life (> 2000 hours).

• Coil resistance: 180Ω±7%.

• Coil inductance: 100 mH±25% (1kHz, 1Vrme).

• INSULATION RESISTANCE VALUE: 10 MΩ MIN (250V).

• Insulation withstand voltage: AC 250V, 1 minute.

• Insulation Type: Class B.

• Linearity: ±0.5°.

• HYSTERESIS: 1.2°MAX.

• Maximum acceleration: 45.103°/s² (with maximum pointer).

• Maximum speed: 720°/s.

• Maximum resting torque: 1 mNm MIN (25mA/phase, 2-phase excitation).

• Moment of attraction of interest: 0.6 mNm MIN (0.5 rps, 180°/s).

Applicable models
PM20T-036 is suitable for a wide range of vehicle brands and models, including but not limited to:

•Audi:

• A6 (2004-2011).

• S6 (2004-2011).

• RS6 (2008-2011).

• Q7 (2005-2014).

• Peugeot: 207.

• Citroën: Berlingo (2004-2008).

•Fiat.

• Iveco.

• Volkswagen: Fox (2005-2011).

• Wuling Glory.

• Haifuxing.

• Palio.

•Beetle.
