1Pcs SPC560B60L3 MCU Chip QFP100 CPU Repair IC New Land Rover KVM Smart Box 18+ Original Chipnet
The SPC560B60L3 parts manufactured by autoecuchips.com are available for purchase at Autoecuchips.com. Here you can find various types and values of electronic parts from the world's leading manufacturers. The SPC560B60L3 components of Autoecuchips.com are carefully chosen, undergo stringent quality control, and are successfully meet all required standards.
The production status marked on Autoecuchips.com is for reference only. If you didn't find what you were looking for, you can get more valuable information by emails, such as the SPC560B60L3 Inventory quantity, preferential price, datasheet, and manufacturer. We are always happy to hear from you, so feel free to contact us.
The SPC560B60L3 is a 32-bit system-on-chip (SoC) microcontroller manufactured by STMicroelectronics and designed for automotive body and gateway applications. The following are detailed information about the chip:
- Features:
- High-performance 64MHz e200z0h CPU
- 32-bit Power Architecture® technology
- Variable Length Encoding (VLE) support
- High-performance processing optimized for low power consumption
- Rich peripheral interfaces and communication functions
Technical Parameters
- CPU:
- 32-bit Power Architecture® technology
- Up to 64MHz operating speed
- Variable Length Encoding (VLE) support
- Auxiliary Processing Unit (APU)
- Memory:
- 1MB Code Flash with ECC
- 64KB Data Flash with ECC
- 80KB SRAM with ECC
- 8-channel Memory Protection Unit (MPU)
- Interrupts:
- 16 priority levels
- Non-maskable interrupts (NMI)
- Up to 51 external interrupt lines, including 27 wake-up lines
- Direct Memory Access (DMA):
- 16-channel eDMA to PITs, DSPIs, ADCs, eMIOS, LINFlex, and I²Cs
- GPIOs:
- 77 GPIOs (LQFP100)
- 121 GPIOs (LQFP144)
- 149 GPIOs (LQFP176)
- Timer unit:
- 8-channel 32-bit cycle interrupt timer
- 4-channel 32-bit system timer
- System Watchdog Timer
- Timer Unit: 8-channel 32-bit cycle interrupt timer 4-channel 32-bit system timer
- eMIOS, 16-bit Counter Timer I/O Unit:
- Up to 64 channels, supports PWM/MC/IC/OC
- Up to 10 counter bases
- Trigger ADC diagnostics via CTU
- Analog-to-Digital Converters (ADCs):
- One 10-bit and one 12-bit ADC, up to 53 channels
- Expandable to 81 channels
- Separate conversion registers
- Cross-trigger unit (CTU)
- Dedicated diagnostic module:
- Advanced PWM generation
- Time-triggered diagnostics
- PWM synchronized ADC measurements
- Bootloader:
- Built-in CAN/UART bootloader
- Communication interfaces:
- Up to 6 FlexCAN interfaces (2.0B active) with 64 message objects each
- Up to 10 LINFlex/UART channels
- Up to 6 buffered DSPI channels
- I²C interface
- Clock generation:
- 4 to 16MHz fast external crystal
- 32kHz slow external crystal
- 16MHz fast internal RC oscillator
- 128kHz slow internal RC oscillator for low power mode
- Software controlled FMPLL
- Clock monitoring unit
- Low Power Functions:
- Multiple low power mode configurations
- Ultra-low power standby with RTC and communication
- Fast wake-up program
- Debugging features:
- Nexus 2+ interface on LBGA208 package
- Nexus 1 interface on all packages
- Power supply:
- Single 5V or 3.3V supply
- Built-in voltage regulator
- External resistor support
- Package type:
- LQFP100
- LQFP144
- LQFP176
- LBGA208 (for Nexus2+)
- Operating temperature range: -40°C to +125°C
Application Scenario
- Car body electronic system: used to control car body electronic equipment, such as windows, doors, lights, etc.
- Gateway Module: Used for automobile internal network communication and data management.
- Engine Control Unit (ECU): for engine ignition and fuel injection control.
- General-purpose power switches: for motors, lamps and solenoid valves, etc.
Summarize
The SPC560B60L3 is a high-performance 32-bit system-on-chip microcontroller for a wide range of automotive body electronics systems and gateway modules. Its high performance CPU, rich memory and peripheral interfaces make it an excellent performer in automotive electronic systems.
