10PCS STA509A STA509 ZIP10 Car Speed Idling Motor Chips Nissan A33 Repair ICs

The STA509A parts manufactured by Sanken are available for purchase at Autoecuchips.com. Here you can find various types and values ​​of electronic parts from the world's leading manufacturers. The STA509A components of Autoecuchips.com are carefully chosen, undergo stringent quality control, and are successfully meet all required standards.

The production status marked on Autoecuchips.com is for reference only. If you didn't find what you were looking for, you can get more valuable information by emails, such as the STA509A Inventory quantity, preferential price, datasheet, and manufacturer. We are always happy to hear from you, so feel free to contact us.

The following is detailed information about the STA509A chip:

- Features:
- Four-channel N-channel MOSFET array
- Low on-resistance (RDS(on) maximum 0.25Ω)
- Continuous drain current of 3A per channel
- Pulsed drain current of ±6A
- Drain-to-source voltage (Vdss) of 57V
- Built-in clamp diodes
- AEC-Q101 qualified for automotive applications

Technical Parameters
- Drain-to-source voltage (Vdss): 57V
- Continuous drain current (Id): 3A
- Pulsed drain current (Id(pulse)): ±6A
- On-resistance (RDS(on)): Maximum 0.25Ω
- Operating temperature range: -40°C to +150°C
- Package type: SIP-10
- Number of pins: 10

Pin Description
- Pin 1: G1 (Gate 1)
- Pin 2: D1 (Drain 1)
- Pin 3: S1 (Source 1)
- Pin 4: G2 (Gate 2)
- Pin 5: D2 (Drain 2)
- Pin 6: S2 (Source 2)
- Pin 7: G3 (Gate 3)
- Pin 8: D3 (Drain 3)
- Pin 9: S3 (Source 3)
- Pin 10: S4 (Source 4)

Precautions
- Compatibility: Before purchasing, please confirm that this chip is compatible with your application and circuit design.
- Installation Instructions:
- Ensure that the soldering temperature meets the specifications.
- Avoid exceeding the rated voltage and current during use.
- Operate and store the device within the specified temperature range.
- Technical Support: For further technical support, it is recommended to contact the supplier or manufacturer. Summary
The STA509A is a four-channel N-channel MOSFET array manufactured by Sanken Electric, suitable for a variety of automotive and industrial applications. Its low on-resistance and high pulse current capability make it perform exceptionally well in various control systems.
