5pcs Original TA2022 TRIPATH ZIP32 Digital Audio Amplifier Amplifier Repair Driver
The TA2022 parts are available for purchase at Autoecuchips.com. Here you can find various types and values of electronic parts from the world's leading manufacturers. The TA2022 components of Autoecuchips.com are carefully chosen, undergo stringent quality control, and are successfully meet all required standards.
The production status marked on Autoecuchips.com is for reference only. If you didn't find what you were looking for, you can get more valuable information by emails, such as the TA2022 Inventory quantity, preferential price, datasheet, and manufacturer. We are always happy to hear from you, so feel free to contact us.
Below are detailed information about the TA2022 ZIP32 chip:
Technical Parameters
- Output power:
- Up to 90W under 4Ω load (per channel)
- Up to 60W under 8Ω load (per channel)
- Operating voltage: ±15V to ±30V
- Switching Frequency: Typical idle switching frequency is approximately 650kHz, with two channels with asynchronous switching patterns and at least 40kHz difference in idle switching frequency.
- Dynamic range: 102dB
- Total Harmonic Distortion (THD):
- Total Harmonic Distortion (THD): 0.015% at 25W (4Ω)
- THD: 0.015% at 25W (4Ω) 0.015% at 60W (8Ω)
- Efficiency:
- 93% at 2 x 60W (8Ω)
- 90% at 2×100W (4Ω)
- Protection: Over-current, over-voltage and under-voltage protection
- Package Type: ZIP32
- Number of pins: 32
Makes and models
- General: TA2022 chips are widely used in the audio systems of many car brands, including but not limited to Mercedes-Benz, BMW, Audi, Volkswagen, etc., to ensure high-quality audio output.
- Other applications: It is also suitable for home and professional audio equipment, such as stereo audio systems, home theater systems, etc.
Precautions
- COMPATIBILITY: Before purchasing, please make sure the chip is compatible with your car audio system.
- Installation Instructions:
- Make sure the chip is mounted in the correct direction and the pins are aligned with the pads on the board.
- During the soldering process, pay attention to temperature control to avoid overheating and damaging the chip.
- Take appropriate static protection measures to avoid static electricity damage to the chip.
- Technical Support: If further technical support is required, it is recommended to contact the supplier or manufacturer.
Summary
The TA2022 ZIP32 is a high-performance digital audio power amplifier chip for a wide range of car audio systems and other audio devices. Its high output power, low distortion and multiple protection features make it an excellent performer in the audio field.
Welcome to our shop!
Dear friends, if you are very interested and want to order a large number, you can contact us through Whatsapp, Wechat, email or Skype, and we will reply to you within 24 hours.
Product Description:
1.The picture only supplies the reference It may not be the exact one as in our stock because of difr NO.
2.We will ship the items within 3 working days after the payment is reached.
3.When the parts arrive at your local customs, if the parts are charged with customs duties, we are not responsible for any customs duties or import taxes.
REFUNDS & RETURN:
We offer a warranty on all items that we sold. Item will be tested before ship, it will be in good condition, if there are some problems with the item, feel free to contact us.
You must contact us before returning any product . Return must be in new condition (Buyer should return all original and undamaged items under re-saleable condition).
Return the goods and the buyer is responsible for all expenses!!
If you are satisfied with our products, please give positive feedback. Thank you for your help. If you are not satisfied, please let us know. Your constructive suggestions will become the driving force for our modification and improvement. Thanks for your understanding.
