The TLP627-2 parts manufactured by TOSHIBA are available for purchase at Autoecuchips.com. Here you can find various types and values of electronic parts from the world's leading manufacturers. The TLP627-2 components of Autoecuchips.com are carefully chosen, undergo stringent quality control, and are successfully meet all required standards.
The production status marked on Autoecuchips.com is for reference only. If you didn't find what you were looking for, you can get more valuable information by emails, such as the TLP627-2 Inventory quantity, preferential price, datasheet, and manufacturer. We are always happy to hear from you, so feel free to contact us.
The following provides detailed information regarding the TLP627-2 optocoupler:
- Features:
- Dual-channel optocoupler
- Optically coupled via a Gallium Arsenide (GaAs) infrared emitting diode and a Darlington-connected phototransistor
- Built-in base-emitter resistor for optimized switching speed and high-temperature characteristics
- High isolation voltage: 5000 Vrms (Min.)
- High collector-emitter voltage: 300 V (Min.)
- High Current Transfer Ratio (CTR): 1000% (Min.)
- UL Certified (UL1577, File No. E67349)
- BSI Certified (BS EN60065: 2002, BS EN60950-1: 2002)
Technical Specifications
- Input Type: DC
- Number of Channels: 2 Channels
- Output Type: Darlington Transistor
- Collector-Emitter Voltage (VCEO): 300 V (Min.)
- Isolation Voltage: 5000 Vrms (Min.)
- Current Transfer Ratio (CTR): 1000% (Min.)
- Input Forward Voltage: 1.15 V (Typ.)
- Input Forward Current: 16 mA (Max.)
- Output Current: 150 mA (Max.)
- Power Dissipation: 150 mW (per channel)
- Rise Time: 40 μs (Typ.)
- Fall Time: 15 μs (Typ.)
- Operating Temperature Range: -55°C to +100°C
- Package Type: DIP-8
- Number of Pins: 8
Pin Configuration
Pin No. Function
1 ANODE (Channel 1)
2 CATHODE (Channel 1)
3 ANODE (Channel 2)
4 CATHODE (Channel 2)
5 EMITTER (Channel 2)
6 COLLECTOR (Channel 2)
7 EMITTER (Channel 1)
8 COLLECTOR (Channel 1) **Application Scenarios**
The TLP627-2 is widely utilized across various fields, including but not limited to:
- Programmable Logic Controllers (PLCs): Used for input/output isolation.
- DC Output Modules: Used for power supply isolation and control.
- Telecommunications Equipment: Used for signal isolation and transmission.
- Industrial Automation: Used for sensor signal isolation.
- Medical Equipment: Used for patient safety and device isolation.
- Power Management: Used for feedback control and isolation.
**Precautions**
- **Compatibility:** Before purchasing, please verify that this photocoupler is compatible with your specific application and circuit design.
- **Installation Guidelines:**
- Ensure that soldering temperatures adhere to the specified requirements.
- Avoid exceeding the rated voltage and current limits during operation.
- Operate and store the device within the specified temperature range.
- **Technical Support:** Should you require further technical assistance, it is recommended that you contact the supplier or manufacturer.
**Summary**
The TLP627-2 is a high-performance, dual-channel photocoupler manufactured by Toshiba. It is well-suited for a wide range of applications requiring high isolation voltage and a high current transfer ratio. Its Darlington output structure and built-in base-emitter resistor enable it to deliver exceptional performance in terms of switching speed and high-temperature characteristics.
Welcome to our shop!
Dear friends, if you are very interested and want to order a large number, you can contact us through Whatsapp, Wechat, email or Skype, and we will reply to you within 24 hours.
Product Description:
1.The picture only supplies the reference It may not be the exact one as in our stock because of difr NO.
2.We will ship the items within 3 working days after the payment is reached.
3.When the parts arrive at your local customs, if the parts are charged with customs duties, we are not responsible for any customs duties or import taxes.
REFUNDS & RETURN:
We offer a warranty on all items that we sold. Item will be tested before ship, it will be in good condition, if there are some problems with the item, feel free to contact us.
You must contact us before returning any product . Return must be in new condition (Buyer should return all original and undamaged items under re-saleable condition).
Return the goods and the buyer is responsible for all expenses!!
If you are satisfied with our products, please give positive feedback. Thank you for your help. If you are not satisfied, please let us know. Your constructive suggestions will become the driving force for our modification and improvement. Thanks for your understanding.
