The V23074-A1001-A403 parts manufactured by TE Connectivity are available for purchase at Autoecuchips.com. Here you can find various types and values of electronic parts from the world's leading manufacturers. The V23074-A1001-A403 components of Autoecuchips.com are carefully chosen, undergo stringent quality control, and are successfully meet all required standards.
The production status marked on Autoecuchips.com is for reference only. If you didn't find what you were looking for, you can get more valuable information by emails, such as the V23074-A1001-A403 Inventory quantity, preferential price, datasheet, and manufacturer. We are always happy to hear from you, so feel free to contact us.
The following are the detailed specifications for V23074-A1001-A403:
- Features:
- Coil Type: DC coil, monostable
- Contact Form: Form C (SPDT-NO, NC)
- Contact Material: Silver-based contact (AgSnO2)
- Suppression resistor mounted on the coil
- IP Rating: IP54
- Operating Temperature Range: -40°C to +125°C
- Dimensions: W23 x D15.5 x H25.4mm
Technical Specifications
- Coil Voltage: 12 VDC
- Maximum Contact Current: 30 A (12V DC/24V DC)
- Coil Resistance: 119Ω
- Coil Power Consumption: 1.2W
- Maximum Switching Voltage: 200V DC
- Operating Temperature Range: -40°C to +85°C
- Electrical Life: 1×10^5 operations
- Mechanical Life: 1×10^7 operations (300 cycles/minute)
- Initial Insulation Resistance: 500MΩ (500V DC)
- Insulation Strength: 500V AC
- Operating Time: Max 10ms
- Release Time: Max 7ms
- Voltage Drop: Typical 20mV at 10A, Max 30mV at 10A
- Vibration Resistance 1: 0Hz-500Hz 176m/s²
- Impulse Resistance: 294m/s²
Precautions
- Compatibility: Before purchasing, please confirm that this relay is compatible with your application and circuit design.
- Installation Instructions:
- Ensure the soldering temperature meets specifications.
- Avoid exceeding rated voltage and current during use.
- Operate and store the device within the specified temperature range.
- Technical Support: For further technical support, please contact the supplier or manufacturer.
In summary, the V23074-A1001-A403 is a high-performance automotive relay manufactured by TE Connectivity, suitable for a variety of automotive electronic applications. Its high contact capacity, low coil power, and multiple protection functions make it excellent in various circuit control systems. If you need to purchase this relay, you can find a suitable supplier through the platforms mentioned above.
