The following are detailed specifications for the V23086-C1002-A803 relay:
- Features:
- Rated Coil Voltage: 12V DC
- Coil Power: 0.6W
- Contact Form: 1 Form C (Single-pole double-throw, 1 CO)
- Contact Rating: Maximum 30A @ 12V DC or 24V DC
- Package Type: DIP package, suitable for through-hole mounting
- Insulation Class: Class F (High temperature resistant)
- Operating Temperature Range: -40°C to +125°C
- High vibration and shock resistance
- Good solder heat resistance
- Compact size, reducing PCB footprint by 50% to only 293 mm²
Technical Parameters
- Coil Voltage: 12V DC
- Coil Power: 0.6W
- Contact Form: 1 Form C (Single-pole double-throw, 1 CO)
- Contact Rating: Maximum 30A @ 12V DC or 24V DC
- Coil Resistance: Approximately 200Ω
- Operating Temperature Range: -40°C to +125°C
- Vibration Resistance: Complies with IEC 68-2-6 standard (sine pulse form)
- Shock Resistance: Complies with IEC 68-2-27 standard (half-sine single pulse)
- Soldering Performance: Hot dip 5 seconds @ 215°C, hot dip 10 seconds @ 245°C, no change in contact switching state > 10 microseconds
Precautions
- Compatibility: Before purchasing, please confirm that this relay is compatible with your application and circuit design.
- Installation Instructions:
- Ensure that the soldering temperature meets the specifications.
- Avoid exceeding the rated voltage and current during use.
- Operate and store the device within the specified temperature range.
- Technical Support: For further technical support, it is recommended to contact the supplier or manufacturer. Summary
The V23086-C1002-A803 is a high-performance relay manufactured by TE Connectivity, suitable for a variety of automotive electronics and industrial applications. Its high contact capacity, low coil power, and multiple protection features make it perform exceptionally well in various circuit control systems.
