Stepper Motor Transparent Shaft VDO Group Repair BMW Porsche Sonata Hyundai Elantra Pointer Stepper Motor Temp Fuel RPM Gauge Instrument Cluster
The VDO Motor instrument Cluster are available for purchase at Autoecuchips.com. Here you can find various types and values of electronic parts from the world's leading manufacturers. The VDO Motor components of Autoecuchips.com are carefully chosen, undergo stringent quality control, and are successfully meet all required standards.
The production status marked on Autoecuchips.com is for reference only. If you didn't find what you were looking for, you can get more valuable information by emails, such as the VDO Motor Inventory quantity, preferential price, datasheet, and manufacturer. We are always happy to hear from you, so feel free to contact us.
Product Overview.
VDO Stepper Motor Transparent Shaft is a kind of stepper motor for automotive dashboards with transparent shaft design, which is mainly used to drive the dashboard pointers (e.g. speedometer, tachometer, fuel gauge, temperature gauge, etc.). This kind of motor is usually used in high-end car brands, such as BMW, Mercedes-Benz, Audi, Porsche, etc.
Main Specifications
- Operating voltage: 12V DC
- Operating temperature range: -40°C to +105°C
- Pointer stepping angle resolution: 1/12°
- Maximum pointer speed: 400Hz
- Current consumption: less than 20mA (5V, 2 × 100mW)
- Dimensions: Φ30mm×7.6mm
- Lifespan: Continuous operation up to 5000 Hz at 200 Hz.
- Compatibility: Compatible with LED PLCC-2 package, can be directly driven by microcontroller.
Application Scenarios
- Automotive instrument panel: Used to drive the pointers of speedometer, tachometer, fuel gauge, temperature gauge, and so on.
- Commercial vehicle instrument clusters: e.g. Volvo Trucks Vn/VNL,FH, etc.
- Compatible models: applicable to a variety of brands and models, such as BMW, Mercedes-Benz, Porsche, Audi, GM, Ford, etc.
Product features
- Transparent shaft design: provides better illumination of the pointer than conventional designs.
- High accuracy: Pointer stepping angle resolution up to 1/12° ensures precise pointer movement.
- High Reliability: Passed various reliability tests, including thermal shock test, humidity test, mechanical vibration test, etc.
- Low Power Consumption: The operating current is less than 20mA, which is suitable for the low power consumption of automobile instrument panel.
Precautions
- Installation: It is recommended to be installed by professionals to ensure the correct operation of the motor.
- Technical Support: If further technical support is required, it is recommended to contact the supplier.
- Compatibility: Before purchasing, please make sure the motor is compatible with your car dashboard.
Summary
The VDO Stepper Motor Transparent Shaft is a high performance automotive dashboard stepper motor for a wide range of makes and models. Its transparent shaft design and high precision features make it competitive in the market.
