5pcs VID29-05 instrument Cluster Motor Repair BYD F3 F6 A5 Car dashboard Stepper motor VID29 05 Original Dashboard Motors
The VID29-05 parts are available for purchase at Autoecuchips.com. Here you can find various types and values of electronic parts from the world's leading manufacturers. The VID29-05 components of Autoecuchips.com are carefully chosen, undergo stringent quality control, and are successfully meet all required standards.
The production status marked on Autoecuchips.com is for reference only. If you didn't find what you were looking for, you can get more valuable information by emails, such as the VID29-05 Inventory quantity, preferential price, datasheet, and manufacturer. We are always happy to hear from you, so feel free to contact us.
VID29-05 is a high-precision stepping motor produced by Weili Drive Technology (Shenzhen) Co., Ltd, which is widely used in automotive instrument panel pointer drive. The following is the detailed information about this motor:
- Features:
- High accuracy: 1/12° micro-step resolution
- High speed: Maximum angular speed 600°/s
- Wide operating voltage: 3.5V to 10V
- Low current consumption: less than 20mA
- Wide operating temperature range: -40°C to +105°C
- Rugged construction: 30mm diameter x 7.6mm height
- Built-in 180:1 gear ratio
Technical specifications
- Operating voltage: 3.5V to 10V
- Current consumption: less than 20mA
- Operating temperature range: -40°C to +105°C
- Stepping angle resolution:
- Full-step mode: 1°
- Half-step mode: 1/3°
- Microstep mode: 1/12° Maximum angular speed: 600°/s
- Maximum angular velocity: 600°/s
- Dynamic torque:
- M200: 1.01.4 mNm (200Hz)
- M400: 0.71.0 mNm (400Hz)
- Static torque: 3.54.0 mNm (at 5V)
- Equivalent motor inertia at output: 4.225×10^-7 kgm²
- Gear ratio: 180:1
- Reverse backlash: 0.51.0°
- Noise level:
- 100'/sec: 34 dBA
- 200'/sec: 41 dBA
- 400'/sec: 44 dBA
Application Scenarios
- Automotive dashboard pointer drive: for speedometer, tachometer, water temperature gauge, oil gauge, etc.
- Digital Instrument System: Converts digital signals to analog display output.
- Motorcycle instrument panel: used for motorcycle instrument display.
- Other instrumentation devices: such as pointer display in industrial equipment.
Precautions
- COMPATIBILITY: Before purchasing, please make sure the motor is compatible with your car's dashboard.
- Technical Support: If further technical support is required, it is recommended to contact the supplier or manufacturer.
- STORAGE CONDITIONS: It is recommended to store in a dry storage cabinet to avoid moisture.
SUMMARY
The VID29-05 is a high performance stepper motor for a wide range of automotive dashboard pointer drive applications. Its high precision, low power consumption and low noise characteristics make it perform well in automotive electronic systems.
