10Pcs/LOT VN820-B5 VN820 VN820B5 TO-263 Smart power switch Repair IC Chipnet
The VN820-B5 parts manufactured by ST are available for purchase at Autoecuchips.com. Here you can find various types and values of electronic parts from the world's leading manufacturers. The VN820-B5 components of Autoecuchips.com are carefully chosen, undergo stringent quality control, and are successfully meet all required standards.
The production status marked on Autoecuchips.com is for reference only. If you didn't find what you were looking for, you can get more valuable information by emails, such as the VN820-B5 Inventory quantity, preferential price, datasheet, and manufacturer. We are always happy to hear from you, so feel free to contact us.
Main Features
- CMOS-compatible input
- Open-state open-circuit load detection
- Closed-state open-circuit load detection
- Short-circuit protection
- Undervoltage and overvoltage shutdown
- Loss of ground protection
- Very low standby current
- Reverse battery protection (optional)
Electrical Parameters
- Operating voltage range: 5.5V-36V
- Maximum output current: 9A
- On-resistance (RDS(on)): 40mΩ (max)
- Delay time: 30µs
- Operating temperature range: -40°C to +150°C
- Maximum power consumption: 65.8W
Package and Pinout
- Package type: P2PAK-5 (surface mount)
- Number of pins: 5 (including grounding tab)
- Mounting method: Surface mount (SMD/SMT)
Application Scenarios
- Automotive electronics: Suitable for electronic control systems of many automotive brands, such as fog lights, windshield wipers, and power seats.
- Industrial Applications: Can be used for industrial equipment that requires high side drive.
Programming Required or Not
- No Programming Required: VN820-B5 is a hardware driver chip, its function is realized by hardware circuit, no programming is required.
- Use of Blank Chip: The blank chip can be used directly for its designed purpose, i.e. as a high side driver to control the load.
Summarize
- Applicable Models and Brands: The VN820-B5 is a general-purpose high-side driver for electronic control systems in a wide range of automobile brands, but there is no exclusive fitment information for specific brands or models.
- Programming Required: The VN820-B5 does not require programming, the blank chip can be used directly.
