VN820PT VN820 PT car BCM original computer board fog lamp control chip,Performance Chip, on-board Computer chip
The VN820PT parts manufactured by ST are available for purchase at Autoecuchips.com. Here you can find various types and values of electronic parts from the world's leading manufacturers. The VN820PT components of Autoecuchips.com are carefully chosen, undergo stringent quality control, and are successfully meet all required standards.
The production status marked on Autoecuchips.com is for reference only. If you didn't find what you were looking for, you can get more valuable information by emails, such as the VN820PT Inventory quantity, preferential price, datasheet, and manufacturer. We are always happy to hear from you, so feel free to contact us.
Main Features
- CMOS-compatible input
- Open-circuit load detection (in both on and off state)
- Short-circuit protection
- Undervoltage and overvoltage shutdown
- Loss of ground protection
- Reverse battery protection
- Electrostatic discharge protection
- Low standby current
- Output current limit
- Output short circuit to VCC detection
Electrical Parameters
- Operating voltage range: 5.5V-36V
- Maximum output current: 9A
- On-resistance (RDS(on)): 40mΩ
- Delay time: 30µs
- Maximum power consumption: 65.8W
- Operating temperature range: -40°C to +150°C
- Standby current: Very low
Package and Pinout
- Package type: PPAK-5 (surface mount)
- Number of pins: 5
- Mounting method: Surface mount (SMD/SMT)
Application Scenarios
- Automotive Electronics: Suitable for electronic control systems of many automotive brands, such as fog lights, windshield wipers, and power seats.
- Industrial Applications: Can be used for industrial equipment that requires high side drive.
Summarize
- Applicable Models and Brands: The VN820PT is a general-purpose high-side driver that is suitable for use in the electronic control systems of a wide range of automobile brands, but there is no exclusive fitment information for a specific brand or model.
- Suggestion: If you need to further confirm the suitability for a specific car model, it is recommended to consult the car manufacturer or a professional automotive electronics engineer.
