The VND5050AJ parts manufactured by STMicroelectronics are available for purchase at Autoecuchips.com. Here you can find various types and values of electronic parts from the world's leading manufacturers. The VND5050AJ components of Autoecuchips.com are carefully chosen, undergo stringent quality control, and are successfully meet all required standards.
The production status marked on Autoecuchips.com is for reference only. If you didn't find what you were looking for, you can get more valuable information by emails, such as the VND5050AJ Inventory quantity, preferential price, datasheet, and manufacturer. We are always happy to hear from you, so feel free to contact us.
The following are detailed specifications for the VND5050AJ chip:
- Features:
- Monolithic device using STMicroelectronics VIPower M0-5 technology
- Used to drive resistive or inductive loads connected to the ground side
- Active VCC pin voltage clamping protects the device from low-energy spikes (compliant with ISO7637 transient compatibility table)
- Integrated analog current sensing provides a current proportional to the load current (according to a known ratio) when the CS_DIS pin is pulled low or left open
- The current sensing pin is in a high-impedance state when the CS_DIS pin is pulled high
- Output current limiting protects the device from overload conditions
- In case of prolonged overload, the device limits power dissipation to a safe level until thermal shutdown intervenes
- Thermal shutdown with automatic restart allows the device to resume normal operation after the fault condition disappears
Technical Parameters
- Operating voltage range: 4.5V to 36V
- Maximum operating temperature: +150°C
- Minimum operating temperature: -40°C
- Maximum output current: 18A (single channel)
- Maximum on-resistance: 50mΩ
- Maximum turn-off time: 35μs
- Maximum ESD voltage: 4kV (HBM)
- Maximum operating frequency: 10kHz (typical)
- Maximum switching energy: 104mJ (L=3mH, RL=0Ω, Vbat=13.5V, Tjstart=150°C, IOUT=IlimL(Typ.))
Precautions
- Compatibility: Before purchasing, please confirm that this chip is compatible with your application and circuit design.
- Installation Instructions:
- Ensure that the soldering temperature meets the specifications.
- Avoid exceeding the rated voltage and current during use.
- Operate and store the device within the specified temperature range.
- Technical Support: For further technical support, it is recommended to contact the supplier or manufacturer.
Summary
The VND5050AJ is a high-performance dual-channel high-side driver manufactured by STMicroelectronics, suitable for automotive electronic systems and industrial and consumer electronics requiring high-reliability power management. Its integrated analog current sensing function and multiple protection mechanisms make it perform exceptionally well in automotive electronic systems. If you need to purchase this chip, you can find suitable suppliers through the platforms mentioned above.
Welcome to our shop!
Dear friends, if you are very interested and want to order a large number, you can contact us through Whatsapp, Wechat, email or Skype, and we will reply to you within 24 hours.
